Specifications
| Waterblock | Dimensions | 113*78*23mm | |
| Base | Copper | ||
| Principalpart | PPS | ||
| Tube | Dimensions | Φ 10*400mm | |
| Material | EPDM | ||
| Power dissipation | 200~2000w | ||
| Compatible Socket&CPU | LGA 4189 3647 4677 TR4 | ||
FEATURES
• Fluorine rubber material is used as sealing material to ensure no leakage.
• Water-block can be used as an ultra-thin structure for heat dissipation in some highly limited tight spaces.
• It can be matched in any form (horizontal and vertical). The water inlet and outlet can be forward, side in, front out and side out, which is suitable for all types of chassis.
• It is mainly used for server/Data center (it can meet 4677, 4189, 3647, TR4 and other standard platforms, and can be customized for non-standard platforms)
