Specifications
| Waterblock | Dimensions | 58*58*28mm | |
| Base | Copper | ||
| Principalpart | PPS | ||
| Pump | Model | A4 | |
| Voltage | 12V | ||
| Speed | 3200RPM | ||
| Radiator | Dimensions | 289*40*40mm*2 | |
| Material | Aluminum | ||
| Tube | Dimensions | Φ13*400mm | |
| Material | EPDM | ||
| Fan | Dimensions | 40*40*28mm | |
| Voltage | 12V | ||
| Speed | 10000RPM | ||
| Air flow{max} | 13.25CFM | ||
| Prerssure{max} | 16.33mm/H20 | ||
| Noise | 44.2 dBA | ||
| Quantity | 10Pcs | ||
| Power dissipation | 300w | ||
| Compatible Socket&CPU | CPU(Intel LGA20XX /115X/1200) | ||
FEATURES
• The pump is integrated with the radiator using the welding technology, which reduces the manual joints and the risk of leakage.
• The size of the radiator can be flexibly adjusted to meet various specifications of the server chassis; For example, 1U, 2U, 3U, 4U.
• Ceramic bearing system in pump guarantees low noise and long working life time.
• Precise helium leakage testing system(HLTS)
