Specifications
| Waterblock | Dimensions | 152*86*29mm | |
| Base | Copper | ||
| Principalpart | PPS | ||
| Pump | Model | A2 | |
| Voltage | 12V | ||
| Speed | 4200RPM | ||
| Radiator | Dimensions | 185*120*27mm | |
| Material | Aluminum | ||
| Tube | Dimensions | Φ13*420mm | |
| Material | EPDM+PU | ||
| Fan | Dimensions | 120*120*25mm | |
| Voltage | 12V | ||
| Speed | 3000RPM | ||
| Air flow{max} | 112.2CFM | ||
| Prerssure{max} | 6.48mm/H20 | ||
| Noise | 44.5 dBA | ||
| Quantity | 2Pcs | ||
| Power dissipation | 300w | ||
| Compatible Socket&CPU | LGA 4189 3647 4677 TR4 | ||
FEATURES
• The pump is integrated with the radiator using the welding technology, which reduces the manual joints and the risk of leakage.
• The size of the radiator can be flexibly adjusted to meet various specifications of the server chassis; For example, 1U, 2U, 3U, 4U.
• Ceramic bearing system in pump guarantees low noise and long working life time.
• Precise helium leakage testing system(HLTS)
